Description

Name:XL-24T timing pulley

XL-24T Timing Pulley with Keyway 24Teeth XL Toothed Pulleys 8/10/12/14/15/16/20mm Bore 11mm Belt Width Transmission Gear Pulley

Model:XL Type

Teeth Number:24T

Teeth Pitch:5.08mm

Inner bore:

Bore 8mm Keyway 3*1.4mm;

Bore 10mm Keyway 3*1.4mm;

Bore 10mm Keyway 4*1.8mm;

Bore 12mm Keyway 4*1.8mm;

Bore 12.7mm Keyway 5*2.3mm;

Bore 14mm Keyway 5*2.3mm;

Bore 15mm Keyway 5*2.3mm;

Bore 16mm Keyway 5*2.3mm;

Bore 17mm Keyway 5*2.3mm;

Bore 18mm Keyway 6*2.8mm;

Bore 19mm Keyway 6*2.8mm;

Bore 20mm Keyway 6*2.8mm;

Belt Width:11mm

Total Height:15mm

Type:Bore with keyway

Screw:2*M5

Material:Aluminum alloy

Package:1pc timing pulley

XL-25T Timing Pulley

Name:XL-25T timing pulley

Model:XL Type

Teeth Number:25T

Teeth Pitch:5.08mm

Inner bore:

Bore 8mm Keyway 3*1.4mm;

Bore 10mm Keyway 3*1.4mm;

Bore 10mm Keyway 4*1.8mm;

Bore 14mm Keyway 5*2.3mm;

Bore 15mm Keyway 5*2.3mm;

Bore 16mm Keyway 5*2.3mm;

Bore 17mm Keyway 5*2.3mm;

Bore 18mm Keyway 6*2.8mm;

Bore 19mm Keyway 6*2.8mm;

Bore 20mm Keyway 6*2.8mm;

Belt Width:11mm

Total Height:15mm

Type:Bore with keyway

Screw:2*M5

Material:Aluminum alloy

Package:1pc timing pulley

Name:XL-25T timing belt

Timing Pulley Clamp Type XL-25T 25Teeth Transmission Belt Pulley 5/6/8/10/12/15mm Bore 11mm Width XL 25T Synchronous Pulley

Model:XL type

Teeth number:25T

Teeth pitch:5.08mm

Inner bore:5/6/8/10/12/14/15mm

Belt Width:11mm

Total Height:25mm

Type:Clamping type

Screw:1*M4

Material:Aluminum alloy

Package:1pc timing pulley

Remark:

*Inner Bore Dia. allowable tolerance:plus(0~0.03mm)

*Total Height/Flange Dia./Teeth Outside Dia./Screw size allow little tolerance between each different batch.

And Customized Timing Pulleys are available for SoCare-MSI®
